Phaser 6300/6350/6360 Color Laser Printer Service Manual 2-21
Theory of Operation
Xerographic Sensor Locations
The following diagrams show the relative position of xerographic sensors.
s6360-374
Temperature/Humidity Sensor
Toner Full Sensor
CTD (ADC) Sensor
CRUM Connector
No Toner Sensors
Toner Cartridge In Sensor
