Phaser 6300/6350/6360 Color Laser Printer Service Manual 2-23
Theory of Operation
Developer Drive Assembly
The Developer Drive Motor drives the four developers housed in the
Developer Unit. The drive transmission route differs depending on the print
mode. For monochrome printing, the developer for the K drum is activated as
shown in the following figure.
Deve Assy (K)
Developer Drive Motor
Gear D2-IN
Gear D5 (1 Way Clutch)
Gear D7
Gear D8
Gear Developer Input (K)
Mag Roll (K)
s6360-342
To Next Page
