Xerox Phaser 6500 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only I – 3
Index
E
EEPROM Board, 2-39
location, 2-38
part number, MFP, 9-38
part number, SFP, 9-32
removal, MFP, 8-161
removal, SFP, 8-139
Electrostatic discharge (ESD), 2-xix
Email Address Book List, A-12
Embedded Pages, A-4 to A-13
Engine test print, 4-47, 5-44
Environmental specifications, 1-22
Erase LED
operation, 2-35
part number, 9-22
removal, 8-97
testing, 4-35
Error Code
Listing and Summary, 3-6 to 3-34
Troubleshooting, 3-35 to 3-164
Error history
system failure, 3-2
Error History Report, A-7
accessing, 3-2
Error Message & Code Summary, 3-6 to 3-34
Error Message Abbreviations, 3-5
Errors, POST, 4-6
Excess toner collection, 2-53
Exit Roller
location, 2-31
Exit Sensor
location, 2-31
operation, 2-31
troubleshooting, 4-23
F
Fan, 2-38
location, 2-38
part number, MFP, 9-36
part number, SFP, 9-30
removal, MFP, 8-141
removal, SFP, 8-119
testing, 4-32
Fasteners, 8-5
Fax
operation, 2-71
Specifications, 1-20
standards, 2-73
Fax Board
location, 2-38
part number, 9-34
removal, 8-143
Fax/Scanner Diagnostic Menu Map, 4-11
Fax/Scanner Diagnostic Tests, 4-51
FB (flatbed) Motor Test, 4-64
Feed Drive Assembly, 2-36, 2-50
color mode switching, 2-36
location, 2-36
part number, 9-28
removal, 8-117
Feed Motor, 2-24
Feed Roller, 2-23
operation, 2-23
part number, 9-19
removal, 8-9
Feed Solenoid, 2-23
Kit part number, 9-17, 9-54
operation, 2-23
removal, 8-49, 8-50
testing, 4-34
Feeder
components, 2-22
feed roller
operation, 2-23
feed solenoid
operation, 2-23
part number, MFP & SFP, 9-17
removal, 8-72
Feeder Assembly
removal, 8-73
Feeder Board, 2-24
Ferrite Core
part number, 9-45
Firmware
update boot firmware, A-16
update main firmware, A-17
FPOT, 1-24
Front Cover
location, MFP, 1-5
location, SFP, 1-4
part number, MFP, 9-12
part number, SFP, 9-8
removal, MFP, 8-33
removal, SFP, 8-22
Front Cover Pivot Shaft, SFP
part number, 9-8
Front Door Retainer Strap removal, MFP, 8-41
Front USB Assembly
removal, 8-158
Front USB Assy
part number, 9-45
Fuser
cooling down, 2-46
drive transmission, 2-49
exit sensor, 2-31
life count, 6-10
location, MFP, 1-9
location, SFP, 1-8
operation, 2-31
part number, 9-26
removal, 8-10
reset life counter, 6-5
temperature
sensing, 2-18
temperature control, 2-46
unfused image, 5-36
warm up, 2-46

Xerox Phaser 6500 Specifications

General

Monthly Duty Cycle	Up to 40, 000 pages
Duplex Printing	Manual
Print Technology	Laser
Maximum Print Resolution	600 x 600 x 4 dpi
First Page Out Time	As fast as 12 seconds
Connectivity	USB 2.0, Ethernet
Paper Capacity	250 sheets + 1 sheet bypass tray
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 24 ppm (color) / Up to 24 ppm (black)
