Xerox Phaser 7400 Service Manual

5-30 Phaser 7400 Color Printer Service Manual
12
Check the Color Registration Shutter.
Run the Service Diagnostics
Registration Shutter test.
Is the shutter functioning correctly?
Go to Step 13. Replace the solenoid
and wiring harness.
13
Are the LED Head ribbon cables
undamaged, properly routed and
seated?
Go to Step 14. Reseat, correctly route
or replace the wiring
harness.
14
Swap the LED Head of the problem
color with any other LED Head.
Print a Supplies page.
Has the problem moved with the LED
Head?
Replace the
defective LED Head
(
page 8-125).
Go to Step15.
15
Replace the Registration Sensor
Board (
page 8-148).
Did this fix the problem?
Complete Go to Step 16.
16
Replace the Engine Control Board
EEPROM.
Did this fix the problem?
Complete. Replace the Engine
Control Board
(
page 8-112).
Troubleshooting Procedure Table (Continued)
Step Actions and Questions Yes No

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
