8-136 Phaser 7400 Color Printer Service Manual
6. Rotate the Top Cover Latch upward, and then remove the 1 (black, plastic 6 mm)
screw that secures the front of the Cyan LED Holder.
Cyan LED Holder
Top Cover Latch
s7400-454
