Xerox Phaser 7400 Service Manual

Parts List 9-5
Parts List 1.1 Main Assembly- Service Parts List
No. Part Number Name/Description
1. 802E99390 Cover-Blank (Dup)
2. 107K02330 LED Head-Unit-53MXF
3. 809E77450 Spring-Head
4. 960K27530 OR-S2V (Engine Control Board)
5. 114K01930 Code-Clump (Cable Clamp, Card Cage)
6. Plate-Clump-HCB (Cable Clamp Retainer)
7. 815E34450 Plate-Beam
8. 815E33950 Plate-Shield
9. 815E33960 Plate-Cover
10. Shaft-Shield
11. 003E77740 Screw-Knob (included in Screw Kit)
12. 032E29850 Block-Lockout-723
13. 032E29860 Block-Lockout-723-2
14. Block-Lockout-723-3
15. Block-Lockout-723-4
16. Block-Lockout-723-5
17. Block-Lockout-723-6
18. 014E61250 Block-Lockout-723-9
19. 032E29870 Block-Lockout-723-10
20. Transfer Unit {See Supplies and Accesories (page 9-58)}
21. Fuser 110 V {See Supplies and Accesories (page 9-58)}
Fuser 220 V
22. Waste Toner Reservoir {See Supplies and Accesories (page 9-58)}
23. Imaging Unit Type C7 C {See Supplies and Accesories (page 9-58)}
24. Imaging Unit Type C7 M {See Supplies and Accesories (page 9-58)}
25. Imaging Unit Type C7 Y {See Supplies and Accesories (page 9-58)}
26. Imaging Unit Type C7 K {See Supplies and Accesories (page 9-58)}
29. Toner-Cart Type C7 Y{See Supplies and Accesories (page 9-58)}
30. Toner-Cart Type C7 M{See Supplies and Accesories (page 9-58)}
31. Toner-Cart Type C7 C{See Supplies and Accesories (page 9-58)}
32. Toner-Cart Type C7 K{See Supplies and Accesories (page 9-58)}
36. Cup_Screw (S Tight M3) (included in Screw Kit)

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
