Xerox Phaser 7400 Service Manual

9-6 Phaser 7400 Color Printer Service Manual
37. Cup_Screw A (included in Screw Kit)
38. 835E10830 Gasket-HCB
39. Indicator-Paper-Size(OKI)
40. 003E77960 Stopper-Paper
41. 802K93850 Case-Cassette-Assy. (Universal Tray)
42.
43. 971537200 IP Board (w/Memory and Configuration Card)
44. 537E66620 EEPROM(CU) (Image Processor Board EEPROM)
45. EEPROM(CU),Key-chip
46. BIOSROM
47. BT100
48. Board-OWF
49. Board-OWF
50. Board-HMY
51. Board-HMY
52. Board-HMY
53. Board-Memory 128MB
54. 856000300 Board-Memory 256MB
55. 856000400 Board-Memory 512MB
61. 121K44690 HDD Assy 20GB (Hard Drive)
62. Compact Flash
63. Nylon Stud
64. Plate-Interface Caulking
65. Plate-Interface Caulking
66. Guide-Rail
67. Plate-Support-PCI
68. Plate-Blank
69. Plate-Blank-N
70. Plate-Blank-W
71. 003E77740 Screw-Knob (included in Screw Kit)
72. Cup_Screw (S Tight M3) (included in Screw Kit)
73. Screw
Parts List 1.1 Main Assembly- Service Parts List
No. Part Number Name/Description

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
