Xerox Phaser 7400 Service Manual

9-12 Phaser 7400 Color Printer Service Manual
120. 802K95170 Cover Assy.-Top
121. Spring-Comp(Joboff)
122. Cover-Duct (R)
123. 802K93890 Cover Assy.-Front (Front Door)
124. 802K93900 Cover Assy.-FU (Side Output Tray)
125. Cover-Guard (L) (Left Front Cover)
126. Cover-Guard(Front) (Upper Front Cover)
127. Cover-Side(L) (Left Side Cover)
128. Cover-Side(L)Rear (Left Rear Cover)
129. Cover-Side(R) (Right Side Cover)
130. Cover-Side(R)Rear (Right Rear Cover)
131. Cover-Rear (Lower Rear Cover)
132. 802K93860 Cover Assy.-OP Panel
133. Film-FG
134. TW-VF-6-0.1X0.8-930 CONN PAR- -
135. Guard-R (Basket Assembly Right Support Rail Cover)
136. Cup_Screw (S Tight M3) (included in Screw Kit)
137. Cup_Screw A (included in Screw Kit)
138. TappingScrew-B2 L=8 (included in Screw Kit)
139. Stay-Rear-MPT (Rear Door A Hinge)
140. Ring
141. Ring
142. SMCD-20-370-AD-P1.0 CONN PAR- -
143. CONN Cord-AMP10P-AMP9P
144. 292254-9 Connector-Plug-
145. CONN Cord-JST3P-JST3P
146. OR-HAL
147. Cover-OP Panel
148. Limiter-Screw
149. Cover-Cable-Heat B
150. Guide-Cable_CU
151. Clamp-Cable
Parts List 2.1 Printer - Service Parts List
No. Part Number Name/Description

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
