Xerox Phaser 7400 Service Manual

Parts List 9-11
88. Holder-ANT
89. Spring-ANT
90. Bracket-ANT
91. Cover-ANT
92. RFID read witer system (CRUM Reader Board)
93. SMCD-9-560BD(1.0) CONN PAR (RFID harness)
94. Plate-Shield-RFID (CRUM Reader Board Cover)
95. 802K93870 Cover Assy.-Top(Sub) (Top Output Chute)
96. Cover-Duct(L)
97. Plate-Shaft-Base
98. Code-Guide
99. Plate-Damper-TCL-Caulking
100. Damper-L
101. Plate-Damper-TCL-SUB
102. Plate-Damper-TCR-Caulking
103. Damper-R
104. Plate-Damper-TCR-SUB
105. Spring-Torsion-Top-L
106. Spring-Torsion-Top-R
107. Shaft-Top
108. Plate-Support(Top)
109. Collar
110. Frame-Duct (Fuser Fan Duct)
111. Motor-Fan (Fuser Fan)
112. Gear-BKL2 (included in Gear Kit)
113. Gear-BKR2 (included in Gear Kit)
114. Spring-Torsion-BAS-L
115. Spring-Torsion-BAS-R
116. 055K36690 Plate-Shield-Box- Assy. (Card Cage)
117. Holder-Duct-FAN-PCB
118. 127E15170 Motor-Fan (Card Cage Fan)
119. DUCT-FAN-PCB (Card Cage Fan Duct)
Parts List 2.1 Printer - Service Parts List
No. Part Number Name/Description

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
