Xerox Phaser 7400 Service Manual

9-10 Phaser 7400 Color Printer Service Manual
32. TappingScrew-B2 L=8 (included in Screw Kit)
33. Plate-Heat
34. Clamp-Cable
35. Stad-Shoulder
36. Photo-Interrupter (Fuser Release Sensor)
37. Cover-Cable-Heat A
38. CONN Cord-JST4P-JST4P (FSRPWR Harness)
39. CONN Cord-JST12P-JST6P,JST7P (FSRSNR Harness)
40. Plate-Guide-ID
41. 054K37700 Gear-Duct-ID- Assy (with 42~50)
42. Bracket-D-Caulking
43. Gear-Bevel
44. Gear-Idle-D
45. Bracket-B-Caulking
46. Gear-Idle
47. Holder-Hall-Duct (Waste Toner Auger Rotation Sensor Holder)
48. Ring
49. Ring
50. Cup_Screw (S Tight M3) (included in Screw Kit)
51. Guide-Tube-L (Auger Tube Guide)
52. 007K14060 Duct-Gear-Assy (with 53 -60) (Waste Toner Auger Assembly)
53. Duct- Assy.-Toner
54. Plate-BKT-Duct A Caulking
55. Plate-BKT-Duct B
56. Gear-Reduction-Tube
57. Gear-Idle-BBD
58. Gear-Idle-D
59. Gear-WT-Z20-Z21
60. Cup_Screw (S Tight M3) (included in Screw Kit)
61. 015K77480 Plate Assy.-MPT Lock (Door A Latch Assy)
86. 023E30870 Motor-Pulse-Belt (Transfer Unit Motor)
87. Gear-Idle-Belt
Parts List 2.1 Printer - Service Parts List
No. Part Number Name/Description

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
