Xerox Phaser 7400 Service Manual

Parts List 9-9
Parts List 2.1 Printer - Service Parts List
No. Part Number Name/Description
1. 032K04400 Cover-Guide-1st-Assy (Door B)
2. Guide-Paper
3. Plate-Stay-A
4. Plate-Stay-B
5. Plate-Support-A
6. Plate-Support-B-Assy
7. Plate-Support-C
8. Motor-DC (Imaging Unit Motor [CMYK])
9. Motor-DC (Fuser Motor)
10. OR-S2M (Motor Driver Board)
11. CONN Cord-HIROSE6P-H2P,H4P
12. CONN Cord-JST2P-JST2P
13. CONN Cord-AMP11P-AMP11P
14. CONN Cord-AMP4P-AMP4P
15. CONN Cord-JST5P-JST4P
16. TW-VF-16-0.1X0.8-420 CONN PAR- -
17. SMCD-40-160BD(1.0) CONN PAR- -
18. SMCD-30-160BD(1.0) CONN PAR- -
19. Film-Guide FFC
20. Shaft-LiftUp
21. Bush
22. 115K02510 Planet Assy.-F
23. Frame-Holder
24. Plate-HV-Base
25. 068K46570 Bracket-HV-Assy (Housing Bias Assembly)
26. 105K29310 PWR unit-(HIGH VOLTAGE) (HVPS)
27. 802K93920 Cover-HV- Assy (with 28~32) (HVPS Cover)
28. Cover-HV
29. Contact-TR
30. Cover-Contact-TR
31. Spring-Fuse-Belt

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
