Xerox Phaser 7400 Service Manual

Parts List 9-23
Parts List 5.1 Xerographics Drive - Service Parts List
No. Part Number Name/Description
0. 007K14170 Side-R-Assy
1. Plate-Side-R-Caulking
2. Guide-Bracket-FU
3. Gear-Z17-FU (included in Gear Kit)
4. Plate-BKT-Fuser
5. Gear-idle(Z39) (included in Gear Kit)
6. Gear-Idle(Z44) (included in Gear Kit)
7. Plate-Side(RER)Caulking
8. Plate-Stacker-Rear
9. Plate-Rail-Rear
10. IMSA-9714N-14Z02 Connector-SQR (Duplex Unit Connector)
11. 010E06290 Slider-Liftup-R (Lift Uplink)
12. Holder-Slider-R
13. Gear-Idle-Link (included in Gear Kit)
14. Planet Assy.-R
15. Gear-Idle-Liftup-Z20-30 (included in Gear Kit)
16. Gear-Idle-Lift-UP-Z37 (included in Gear Kit)
17. Bracket-Inner-Caulking
18. Guide-Cable-A
19. Guide-Cable-B
20. Guide-Rear (Toner Supply Housing)
21. 960K33020 OR-SGG (Imaging Unit Sensor Board)
22. 127E15180 Motor-Pulse (Toner Motors)
23. Plate-Motor
24. Cup_Screw (S Tight M3) (included in Screw Kit)
25. Gear-Z14-42 (included in Gear Kit)
26. Gear-Z14-35 (included in Gear Kit)
27. 008E08270 Camshat (Toner Supply Camshaft)
28. 809E71630 Spring-ID-Fuse (Imaging Unit Contact Springs)
29. 809E71640 Spring-FG
30. 809E71810 Spring-Press-FG

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
