9-24 Phaser 7400 Color Printer Service Manual
31. CONN Cord-JST9P-AMP3P,JST3PX2 (IDFAN Harness)
32. CONN Cord-JST24P-JST24P (CTG0 Harness)
33. Gear-Idle-Drum (included in Gear Kit)
34. Plate-Bracket-Outer
35. Guide-Cable-FU
36. CONN Cord-AMP13P-AMP7P,AMP7P (DUPLEX Harness)
37. Cup_Screw (S Tight M3) (included in Screw Kit)
38. 292254-3 Connector-Plug-
39. Cup_Screw A (included in Screw Kit)
40. Clamp-Cable
41. Ring
42. Ring
43. Plate-Planet
44. Post-Planet-A
45. Post-Planet-B
46. Spring-Planet
47. Washer
48. 127E15140 Motor-Fan (Transfer Unit Fan)
49. Screw (SW+2W) (included in Screw Kit)
50. CONN Cord-JST5P-SW (Door A Interlock Switch)
51. Plate-Support-D
52. Screw-PSW2W2-10C
53. Gear-Z77-FU (included in Gear Kit)
54. Gear-Z47-FU
55. Gear-Z14-Z24-FU
56. Gear-Planet-Z16-FU (included in Gear Kit)
57. Gear-Z20-FU (included in Gear Kit)
58. Gear-Z17-FU (included in Gear Kit)
59. Gear-Z16-FU (included in Gear Kit)
60. Bush-4
61. Bush-6
62. Bush-6
Parts List 5.1 Xerographics Drive - Service Parts List
No. Part Number Name/Description

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
