Xerox Phaser 7400

10-32 Phaser 7400 Color Printer Service Manual
Motor Driver Board (2/6)
Motor Drive Board
TNRMOT0
1
2
Toner Motor CM
FAN
1
2
3
Card Cage Fan
M
3
4
WTDC
1
2
4
5
6
Waste Toner Motor
3
7
8
9
M
+5VDC+24VDC
TNRMOT1
1
2
Toner Motor YK
M
M
3
4
+24VDC
P/J50
1
2
6
3
4
5
7
8
9
DCHEAT
1
2
4
5
6
Fuser Motor
3
7
8
9
M
M
s7400-366
BELT FAN
1
2
3
Transfer Unit Fan
+24VDC
+24VDC
GND
FANALM
+24V
GND
FANERR1
GND
+5V
+24V
GND
WTON_N
LOCK
WTCWCCW
WTCLK
GND
+5V
+24V
GND
HETON_N
HETLOCK
HETCWCEW
GAINHT
HETCLK
GAIN
+5VDC+24VDC
