A-6 Phaser 7400 Color Printer Service Manual
U8 Controller Fan Failure. The Rotation signal from the I/P Board Fan indicates a failure.
U9 Power Supply Fan Failure. The Rotation signal from the LVPS Fan indicates a failure.
U10 Top Cover Fan Failure. The Rotation signal from the Top Cover Fan indicates a failure.
U11 Imaging Unit Front Fan Failure. The Rotation signal from the Imaging Unit Front Fan
indicates a failure.
U12 Duplex Interface Failure. Communication error between the Engine Control Board and
Duplex Unit.
U13 Tray 4 Interface Failure. Communication error between the Engine Control Board and
HCF.
U14 Tray 3 Interface Failure. Communication error between the Engine Control Board and
LTA.
U16 Tray 5 Interface Failure.
U17 Tray 6 Interface Failure.
U18 Yellow LED Failure.
U19 Magenta LED Failure.
U20 Cyan LED Failure.
U21 Black LED Failure.
U26 Yellow Imaging Unit Failure. Yellow drum out of position (Up/Down).
U27 Magenta Imaging Unit Failure. Magenta drum out of position (Up/Down).
U28 Cyan Imaging Unit Failure. Cyan drum out of position (Up/Down).
U29 Black Imaging Unit Failure. Black drum out of position (Up/Down).
U30 Flash Hardware Failure. Flash Memory failure on the Engine Control Board.
U31 Flash Software Failure. Firmware error in Engine Control Board Flash Memory.
U32 Fuser Fan Failure. The Rotation signal from the Fuser Fan indicates a failure.
U33 Fuser Voltage mismatch Failure. The Fuser voltage rating does not match the supply.
U34 Flash memory failure in the Duplex Unit.
U35 Unsupported Tray 3 ROM. The Tray 3 firmware is unsupported.
U36 Unsupported Tray 4 ROM. The Tray 4 firmware is unsupported.
U37 Unsupported Tray 5 ROM. The Tray 5 firmware is unsupported.
U38 Unsupported Tray 6 ROM. The Tray 6 firmware is unsupported.
U39 Unsupported Tray 2 ROM. The Tray 2 firmware is unsupported.
U40 Imaging Unit Rear Fan Failure.
U41 Engine Cavity Fan Failure. The Card Cage Fan has failed.
U50 Unsupported Inverter Unit. The Inverter firmware is unsupported.
Printer Status Codes (Continued)
Code Description

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
