Xerox Phaser 7400 Service Manual

Reference A-7
U51 Inverter Unit Interface Failure.
U55 Unsupported Finisher Unit. The Finisher firmware is unsupported.
W16 Fuser Fuse Cut Error. The printer checks the consumables at power on and when a cover
is closed. If a comsumable fuse is detected, the printer will cut it and clear the
consumable counter. If the fuse does not blow, this error persits.
W17 Transfer Unit Fuse Cut Error. The printer checks the consumables at power on and when
a cover is closed. If a comsumable fuse is detected, the printer will cut it and clear the
consumable counter. If the fuse does not blow, this error persits.
W18 Cyan Imaging Unit Fuse Cut Error. The printer checks the consumables at power on and
when a cover is closed. If a comsumable fuse is detected, the printer will cut it and clear
the consumable counter. If the fuse does not blow, this error persits.
W19 Magenta Imaging Unit Fuse Cut Error. The printer checks the consumables at power on
and when a cover is closed. If a comsumable fuse is detected, the printer will cut it and
clear the consumable counter. If the fuse does not blow, this error persits.
W20 Yellow Imaging Unit Fuse Cut Error. The printer checks the consumables at power on and
when a cover is closed. If a comsumable fuse is detected, the printer will cut it and clear
the consumable counter. If the fuse does not blow, this error persits.
W21 Black Imaging Unit Fuse Cut Error. The printer checks the consumables at power on and
when a cover is closed. If a comsumable fuse is detected, the printer will cut it and clear
the consumable counter. If the fuse does not blow, this error persits.
F93 Finisher Jog Motor Failure.
F103 Finisher Paddle Motor Failure.
F106 Finisher Stapler Swing Motor Failure.
F110 Finisher Staple Motor Failure.
F111 Finisher Stapler Stack Handling Motor Failure.
F115 Finisher Tray Lift Motor Failure.
F116 Finisher Exit Motor Failure.
F130 Engine Communications Failure.
F131 Finisher Folder Sensor Failure.
F132 Finisher Punch Communications Failure.
F133 Finisher Punch Side Registration Motor Failure.
F134 Finisher Punch Motor Failure.
F136 Finisher Punch Registration Motor Failure.
F137 Finisher Backup RAM Failure.
F138 Finisher Punch Backup RAM Failure.
F139 Finisher Punch Waste Sensor Failure.
F140 Finisher Punch Motor Failure.
Printer Status Codes (Continued)
Code Description

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
