Xerox Phaser 7400 Service Manual

Reference A-23
Paddle Home
Position Sensor
Paddle is Home/Not Home
Bookbinding
Clock Sensor
Clock is High/Low
Tray Lift Motor
Clock
Clock is High/Low
Punch
Connected
Signal
Punch is Connected/Not Connected
Inverter Input
Sensor
Input Sensor On/Off
Inverter Output
Sensor
Output Sensor On/Off
Inverter Exit
Sensor
Exit Sensor signal On/Off
Inverter Cover
Switch
Cover Switch Open/Closed
Inverter Lower
Sensor
Lower Inverter Sensor is On/Off
Inverter Joint
Sensor
Inverter Joint Sensor is On/Off
Inverter CNT2
Signal
CNT2 Signal is On/Off NOTE: At the time of publication,
this test was not functional.
Finisher Solenoid Tests - Tests display the status of each solenoid.
Inverter
Seperator
Solenoid
Solenoid is On Listen for the click.
<Press Back or Cancel to abort>
<Auto abort in 10 seconds>
Inverter
Pressure
Solenoid
Solenoid is On Listen for the click.
<Press Back or Cancel to abort>
<Auto abort in 10 seconds>
Finisher Clutch Tests - Tests display the status of each clutch.
Saddle Stiching
Clutch
Clutch is On Listen for the clutch to engage.
<Press Back or Cancel to abort>
<Auto abort in 10 seconds>
Inverter
Registration
Clutch
Clutch is On Listen for the clutch to engage.
<Press Back or Cancel to abort>
<Auto abort in 10 seconds>
Service Diagnostics Tests and Utilities (Continued)
Menu Item Front Panel Display Results Functional Definition

Xerox Phaser 7400 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	12 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Print speed (color, normal quality, A4/US Letter)	36 ppm
Storage media	HDD
Internal memory	512 MB
Processor model	PowerPC
Maximum internal memory	1 MB
Internal storage capacity	20 GB
Total input capacity	800 sheets
Maximum input capacity	3000 sheets
Paper tray 2 input capacity	350 sheets
Auto document feeder (ADF) input capacity	1650 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Labels, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
Maximum ISO A-series paper size	A3
Power requirements	100-240V, 50/60Hz
Networking features	Fast Ethernet
Supported media weight(s)	270 g/m²
Maximum operating temperature range (T-T)	10 - 32 °C
Certification	FCC p.15 A, CE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-4 - 140 °F
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Maximum duty cycle	150000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	1438 x 623 x 975 mm
