E5071C
188
3. Click Modify Kit. To change the pre-defined connector type (e.g.
OPEN(f) to OPEN (m)) skip to the specifty classes.
4. Click Define STDs.
5. Select the standard to be redefined from among standards numbered
1 through 21.
6. Click No Name > Label and input a new label for the standard using
the keypad displayed on the screen.
Procedure to select the standard type and define standard coefficient
1. Press Cal key.
2. Click Modify Kit.
3. Click Define STDs and select the standard to be redefined from
among standards numbered 1 through 21.
4. Click STD Type, then select the type of standard.
Softkey Function
Open
Selects the OPEN standard
Short
Selects the SHORT standard
Load
Selects the LOAD standard
Delay/Thru
Selects the delay/THRU standard
Unknown Thru
Selects the Unknown THRU standard
Arbitrary
Selects the arbitrary impedance
None
Selects no standard type
5.
6. Set the standard coefficient.
Softkey Function
C0
Sets C0
