Measurement
199
Possible cases of frequency ranges
Execution of
calibration
Example 1, When frequency ranges specified with
subclasses overlap
Possible
Example 2, When frequency ranges specified with
subclasses do not cover a part of a measurement
frequency range
Impossible
Example 3, When a frequency range specified with
a subclass lies outside the measurement frequency
range
Possible
Example 4, When a part of a frequency range
specified with a subclass lies outside the
measurement frequency range
Possible
Example 1, When frequency ranges specified with subclasses overlap
For the measurement frequency range (1 GHz - 8 GHz), if you execute
calibration with a standard of subclass 1 (1 GHz-5 GHz) and then with a
standard of subclass 2 (4 GHz-8 GHz), the standard last executed is
applied for the overlapping portion (4 GHz-5 GHz).
Example 2, When frequency ranges specified with subclasses do not cover a part of a measurement frequency range
For a measurement frequency range (1 GHz to 8 GHz), if you execute
calibration with a standard of subclass 1 (1 GHz to 5 GHz) and then with a
standard of subclass 2 (6 GHz to 8 GHz), Done is NOT available for the
undefined portion (5 GHz-6 GHz).
