E5071C
2758
TRIGGER
SCPI.TRIGger.OUTPut.POLarity
Object type
Property (Read-Write)
Syntax
SCPI.TRIGger.OUTPut.POLarity=param
param=SCPI.TRIGger.OUTPut.POLarity
Description
This command sets/gets the polarity of the pulse generated by the External
Trigger Output Port.
Variable
Parameter Param
Description
Sets/Gets polarity of the pulse generated by the output
trigger.
Data type Character string type (String)
Range
Select from either of the following:
• "POSitive": Generates a Positive pulse.
• "NEGative": Generates a Negative pulse.
Preset
value
"POSitive"
Examples
Dim TrigPol As String
TrigPol="NEGative"
SCPI.TRIGger.OUTPut.POLarity=TrigPol
Related objects
SCPI.TRIGger.OUTPut.POSition
SCPI.TRIGger.OUTPut.STATe
Equivalent key
Trigger > Polarity
Equivalent SCPI command
Syntax
