Programming
2773
SCPI.TRIGger.SEQuence.POINt
Type of object
Property (Read-Write)
Syntax
SCPI.TRIGger.SEQuence.POINt = Status
Status = SCPI.TRIGger.SEQuence.POINt
Description
This command turns ON/OFF or returns the status of the point trigger
feature.
• When the point trigger feature is turned on, if the sweep mode
is Swept, it changes to Stepped.
When the trigger source is set to the internal trigger (Internal),
the setting is ignored.
Variable
Parameter Status
Description Turns ON/OFF the point trigger
Data type Boolean type (Boolean)
Range
Select from either of the following:
True or ON: Turns on the point trigger.
False or OFF: Turns off the point trigger.
Preset value False or OFF
Note
Example of use
Dim Ptrig As Boolean
SCPI.TRIGger.SEQuence.POINt = True
Ptrig = TRIGger.SEQuence.POINt
Related objects
SCPI.TRIGger.SEQuence.SOURce
Equivalent key
Trigger > Trigger Event
