Agilent Technologies E5071C - Page 2562

Programming
2789
:CALCulate:DEVice
Type
Command/Query
Syntax
:CALCulate:DEVice {SEND1|SEND2|DIF1|SEND4|DIF2}
:CALCulate:DEVice?
Description
This command sets DUT topology.
Parameter
Description DUT topology
Data Type Character string type (String)
Range
SEND1: Single-Ended 1-Port
SEND2: Single-Ended 2-Port
DIF1: Deferential 1-Port
SEND4: Single-Ended 4-Port
DIF2: Deferential 2-Port
Preset Value SEND1
Unit -
Resolution -
Query Response
{SEND1|SEND2|DIF1|SEND4|DIF2}<newline><^END>
Examples
10 OUTPUT 717;":CALC:DEV SEND1"
20 OUTPUT 717;":CALC:DEV?"
30 ENTER 717;A$
Equivalent GUI
Setup > DUT Topology (under Basic)
