Programming
2793
:CALCulate:EYE:INPut:BPATtern:TYPE
Type
Command/Query
Syntax
:CALCulate:EYE:INPut:BPATtern:TYPE {PRBS|K285|USER}
:CALCulate:EYE:INPut:BPATtern:TYPE?
Description
This command sets the bit pattern type for the simulated eye function.
Parameter
Description Bit pattern type
Data Type Character string type (String)
Range
PRBS: Pseudo-Random Bit Sequence
K285: K 28.5
USER: User Custom
Preset Value PRBS
Unit -
Resolution -
Query Response
{PRBS|K285|USER}<newline><^END>
Examples
10 OUTPUT 717;":CALC:EYE:INP:BPAT:TYPE K285"
20 OUTPUT 717;":CALC:EYE:INP:BPAT:TYPE?"
30 ENTER 717;A$
Related Commands
:CALCulate:EYE:INPut:BPATtern:LENGth
:MMEMory:LOAD:EYE:BPATtern
Equivalent GUI
Eye Mask > Type (under Bit Pattern)
