E5071C
2794
:CALCulate:EYE:INPut:DRATe
Type
Command/Query
Syntax
:CALCulate:EYE:INPut:DRATe <numeric>
:CALCulate:EYE:INPut:DRATe?
Description
This command sets the bit rate for the simulated eye function.
Parameter
Description Bit Rate
Data Type Double precision floating point type (Double)
Range -
Preset Value 1G
Unit bits/sec
Resolution -
Query Response
{numeric}<newline><^END>
Examples
10 OUTPUT 717;":CALC:EYE:INP:DRAT 1.1e9"
20 OUTPUT 717;":CALC:EYE:INP:DRAT?"
30 ENTER 717;A
Related Commands
:CALCulate:EYE:INPut:OLEVel
:CALCulate:EYE:INPut:ZLEVel
:CALCulate:EYE:INPut:RTIMe:DATA
:CALCulate:EYE:INPut:RTIMe:THReshold
Equivalent GUI
Eye/Mask > Data Rate (Under Bit Pattern)
