Agilent Technologies E5071C - Page 2572

Programming
2799
:CALCulate:EYE:MASK:FAIL
Type
Query Only
Syntax
:CALCulate:EYE:MASK:FAIL?
Description
This command returns the mask test result.
Parameter
Description Mask test result
Data Type Boolean type (Boolean)
Range
1: Mask Test Fail
0: Mask Test Pass
Preset Value -
Unit -
Resolution -
Query Response
{1|0}<newline><^END>
Examples
10 OUTPUT 717;":CALC:EYE:STAT ON"
20 OUTPUT 717 ":CALC:ATR:ACT 3"
30 OUTPUT 717;":MMEM:LOAD:EYE:MASK ""D:\TDR\FC0133.msk"""
40 OUTPUT 717;":CALC:EYE:MASK:STAT ON"
50 OUTPUT 717;":CALC:EYE:EXEC""
60 OUTPUT 717;":CALC:EYE:MASK:FAIL?"
70 ENTER 717;A
Related Commands
:CALCulate:EYE:MASK:STATe
Equivalent GUI
Eye/Mask > Mask Test Result in windows
