:CALCulate:EYE:MASK:STATe
Type
Command/Query
Syntax
:CALCulate:EYE:MASK:STATe {ON|OFF|1|0}
:CALCulate:EYE:MASK:STATe?
Description
This command sets mask test with simulated eye on/off.
Parameter
Description Mask Test ON/OFF
Data Type Boolean type (Boolean)
Range ON|OFF|1|0
Preset Value OFF
Unit -
Resolution -
Query Response
{1|0}<newline><^END>
Examples
10 OUTPUT 717;":CALC:EYE:STAT ON"
20 OUTPUT 717 ":CALC:ATR:ACT 3"
30 OUTPUT 717;":MMEM:LOAD:EYE:MASK ""D:\TDR\FC0133.msk"""
40 OUTPUT 717;":CALC:EYE:MASK:STAT ON"
50 OUTPUT 717;":CALC:EYE:EXEC"
Related Commands
:CALCulate:EYE:MASK:STATe
:CALCulate:EYE:EXECute
:CALCulate:EYE:MASK:FAIL
:MMEMory:LOAD:EYE:MASK
Equivalent GUI
Eye Mask > Mask Test (Under Result)
