Programming
2801
:CALCulate:EYE:RESults:DATA
Type
Query Only
Syntax
:CALCulate:EYE:RESults:DATA?
Description
This command returns the results of eye measurement. The 18 values are
returned. The minimum and maximum values are returned in addition of
the displayed results (16 values) on the TDR application GUI.
Parameter
Description Results of eye measurement
Data Type Variant type Array (Range)
Range -
Preset Value
-
Unit -
Resolution -
Query Response
{numeric (Minimum Value)},{numeric (Maximum Value)},{numeric (Level
Zero)},{numeric (Level One)}, {numeric (Level Mean)},{numeric
(Amplitude)},{numeric (Height)},{numeric (always 0)}, {numeric
(Width)},{numeric (Opening Factor)}, {numeric (Signal/Noise Ratio)},
{numeric (Duty Cycle Distortion)},{numeric (Duty Cycle Distortion-
%)},{numeric (Rise Time)},{numeric (Fall Time)},{numeric (Jitter peak to
peak)},{numeric (Jitter RMS)},{numeric (Crossing
Percentage)}<newline><^END>
Examples
10 OUTPUT 717;":CALC:EYE:STAT ON"
20 OUTPUT 717 ":CALC:ATR:ACT 3"
30 OUTPUT 717;":CALC:EYE:RES:THR T2_8"
30 OUTPUT 717;":CALC:EYE:EXEC"
40 OUTPUT 717;":CALCulate:EYE:RESults:DATA?"
50 ENTER 717;A(*)
Related Commands
:CALCulate:EYE:RESults:THReshold
