Agilent Technologies E5071C - Page 2576

Programming
2803
:CALCulate:EYE:RESults:DISPlay:STATe
Type
Command/Query
Syntax
:CALCulate:EYE:RESults:DISPlay:STATe {ON|OFF|1|0}
:CALCulate:EYE:RESults:DISPlay:STATe?
Description
This command turns the overlay on/off.
Parameter
Description Overlay on/off
Data Type Boolean type (Boolean)
Range ON|OFF|1|0
Preset Value ON
Unit -
Resolution -
Query Response
{1|0}<newline><^END>
Examples
10 OUTPUT 717;":CALC:EYE:STAT ON"
20 OUTPUT 717 ":CALC:ATR:ACT 3"
30 OUTPUT 717;":CALC:EYE:EXEC"
40 OUTPUT 717;":CALC:EYE:RES:DISP:STAT OFF"
Related Commands
:CALCulate:EYE:RESults:DATA
Equivalent GUI
Eye Mask > Overlay (Under Result)
