:CALCulate:TRACe{Tr}:GATE:STOP
Type
Command/Query
Syntax
:CALCulate:TRACe{Tr}:GATE:STOP <numeric>
:CALCulate:TRACe{Tr}:GATE:STOP?
Description
This command sets stop value for the gating function.
Parameter
Description Stopping point of the gate
Data Type Double precision floating point type (Double)
Range -
Preset Value 10n
Unit -
Resolution -
Query Response
{numeric}<newline><^END>
Examples
10 OUTPUT 717;":CALC:TRAC1:GATE:STAR 2e-9"
20 OUTPUT 717;":CALC:TRAC1:GATE:STOP 6e-9"
30 OUTPUT 717;":CALC:TRAC1:GATE:TYPE BPAS"
40 OUTPUT 717;":CALC:TRAC1:GATE:STAT ON"
50 OUTPUT 717;":CALC:TRAC1:GATE:STOP?"
60 ENTER 717;A
Related Commands
:CALCulate:TRACe{Tr}:GATE:STARt
:CALCulate:TRACe{Tr}:GATE:TYPE
:CALCulate:TRACe{Tr}:GATE:STATe
Equivalent GUI
TDR/TDT > Gating > Stop virtual knob OR
TDR/TDT > Gating > type in the text box under the Stop virtual knob OR
Right-click on the time domain graph plot and select Set Gating Range
