Programming
2819
:CALCulate:TRACe{Tr}:GATE:TYPE
Type
Command/Query
Syntax
:CALCulate:TRACe{Tr}:GATE:TYPE {BPASs|NOTCh}
:CALCulate:TRACe{Tr}:GATE:TYPE?
Description
This command sets gate type for the gating function
Parameter
Description Gate type for the gating function
Data Type Character string type (String)
Range
BPASs: Band Pass
NOTCh: Notch
Preset Value BPASs
Unit -
Resolution -
Query Response
{BPASs|NOTCh}<newline><^END>
Examples
10 OUTPUT 717;":CALC:TRAC1:GATE:STAR 2e-9"
20 OUTPUT 717;":CALC:TRAC1:GATE:STOP 6e-9"
30 OUTPUT 717;":CALC:TRAC1:GATE:TYPE BPAS"
40 OUTPUT 717;":CALC:TRAC1:GATE:STAT ON"
50 OUTPUT 717;":CALC:TRAC1:GATE:TYPE?"
60 ENTER 717;A
Related Commands
:CALCulate:TRACe{Tr}:GATE:STARt
:CALCulate:TRACe{Tr}:GATE:STOP
:CALCulate:TRACe{Tr}:GATE:STATe
Equivalent GUI
TDR/TDT > Gating > Notch OR Bandpass (under Type)
