Programming
2833
:CALCulate:TRACe{Tr}:TIME:STEP:RTIMe:DATA
Type
Command/Query
Syntax
:CALCulate:TRACe{Tr}:TIME:STEP:RTIMe:DATA <numeric>
:CALCulate:TRACe{Tr}:TIME:STEP:RTIMe:DATA?
Description
This command sets rise time value for the transform function.
Parameter
Description Transform function rise time value
Data Type Double precision floating point type (Double)
Range 15.9p to 20.8n
Preset Value 35p
Unit sec
Resolution -
Query Response
{numeric}<newline><^END>
Examples
10 OUTPUT 717;":CALC:TRAC1:TIME:STEP:RTIM:DATA 0"
20 OUTPUT 717;":CALC:TRAC1:TIME:STEP:RTIM:DATA?"
30 ENTER 717;A
Related Commands
:CALCulate:TRACe{Tr}:TIME:STEP:RTIMe:THReshold
:CALCulate:TRACe{Tr}:TIME:STIMulus
Equivalent GUI
TDR/TDT > Parameters > Entry box (In Rise Time)
