E5071C
2896
1. Set IDs of connected multiport test sets to different values. The
instruments will not work correctly if their IDs are the same. For
more information, see Selecting ID for Multiport test Set.
2. Press System key > Multiport Test Set Setup to display the multiport
test set setup menu.
3. Select Test Set 1 for the test set with ID 1 and Test Set 2 for ID 2.
4. The E5091A (option 009 and 016) and the E5092A (option 020)
can be used at the same time.
Recommended Wrench
When using a semi-rigid cable, connect the semi-rigid cable to a test port
of the multiport test set with a specified torque using a torque wrench.
Specified torque 5.7 kgf-cm/ 56 N-cm / 5 in-lb
Recommended wrench Wrench (Agilent part number 8710-1582)
