E5071C
266
The trigger source generates a cue signal that initiates a measurement
process. Four types of trigger sources are available.
Trigger
Sources
Function
Internal
(Internal)
Uses a consecutive signal generated by the firmware as
a trigger source. Triggers are sent immediately following
the completion of each measurement.
External
(External)
Uses the external trigger input terminal (BNC) or
Handler I/O (Pin No. 18) as a trigger source.
Manual
(Manual)
A trigger is generated by pressing Trigger > Trigger.
Bus (Bus) A trigger is generated through GPIB/LAN/USB.
Trigger Scope
The Trigger Scope specifies the scope of the triggering, whether it is for all
channels (default) or for the selected channel.
When this function is enabled with a value of "ACTive", only active channel
is triggered. When this function is enabled with a value of "ALL", all
channels of the E5071C are triggered.
For example, if Trigger Scope is set to "ACTive" when Trigger > Continuous
is selected for all channels, a measurement channel is automatically
changed by switching over the active channel.
Trigger Scope Function
All Channel Triggers ALL channels which are in "Initiate" status
Active Channel Triggers Active channel which is in "Initiate" status
Trigger Mode
You can set the trigger mode for each channel independently. This allows
you to control the operation of each channel after a trigger signal is
detected by setting the channel's status with the trigger mode.
Trigger mode
name
Function
Sweep stop
(Hold)
The status ("Idle" status) in which the sweep is
stopped. When a trigger signal is detected, the
