Agilent Technologies E5071C User Manual

E5071C
334
T21(complex a, complex b,
complex c, complex d)
T
21
conversion = -d/b
T21(scalar i, scalar j) returns T21(Sii, Sji, Sij, Sjj)
T22(complex a, complex b,
complex c, complex d)
T
22
conversion = 1/b
T22(scalar i, scalar j) returns T22(Sii, Sji, Sij, Sjj)
Y11(complex a, complex b,
complex c, complex d)
Y
11
conversion = (1/Z0)*((1-a)*(1+d) +
b*c)/((1+a)*(1+d) - b*c)
Y11(scalar i, scalar j) returns Y11(Sii, Sji, Sij, Sjj)
Y12(complex a, complex b,
complex c, complex d)
Y
12
conversion = (1/Z0)*(-2*c)/((1+a)*(1+d) -
b*c)
Y12(scalar i, scalar j) returns Y12(Sii, Sji, Sij, Sjj)
Y21(complex a, complex b,
complex c, complex d)
Y
21
conversion = (1/Z0)*(-2*b)/((1+a)*(1+d) -
b*c)
Y21(scalar i, scalar j) returns Y21(Sii, Sji, Sij, Sjj)
Y22(complex a, complex b,
complex c, complex d)
Y
22
conversion = (1/Z0)*((1+a)*(1-d) +
b*c)/((1+a)*(1+d) - b*c)
Y22(scalar i, scalar j) returns Y22(Sii, Sji, Sij, Sjj)
Z11(complex a, complex b,
complex c, complex d)
Z
11
conversion = Z0*((1+a)*(1-d) + b*c)/((1-
a)*(1-d) - b*c)
Z11(scalar i, scalar j) returns Z11(Sii, Sji, Sij, Sjj)
Z12(complex a, complex b,
complex c, complex d)
Z
12
conversion = Z0*(2*c)/((1-a)*(1-d) - b*c)
Z12(scalar i, scalar j) returns Z12(Sii, Sji, Sij, Sjj)
Z21(complex a, complex b,
complex c, complex d)
Z
21
conversion = Z0*(2*b)/((1-a)*(1-d) - b*c)
Z21(scalar i, scalar j) returns Z21(Sii, Sji, Sij, Sjj)
Z22(complex a, complex b, Z
22
conversion = Z0*((1-a)*(1+d) + b*c)/((1-
