Agilent Technologies E5071C User Manual

Quick Start
39
When a memory
trace is ON, see the
contents inside ()
D- M (D- M&M)
Execution of Data- Mem
math
D*M (D*M&M)
Execution of Data*Mem
math
D/M (D/M&M)
Execution of Data/Mem
math
Electrical delay
Del
A numeric value other
than 0 (zero) is specified
as the electrical delay or
phase offset.
Smoothing
Smo
Smoothing: ON
Gating
Gat
Gating: ON
Parameter
conversion
Zr
Conversion: ON
(Impedance: Reflection
measurement)
Zt
Conversion: ON
(Impedance:
Transmission
measurement)
Ztsh
Conversion: ON
(Impedance:
Transmission-Shunt
measurement)
Yr
Conversion: ON
(Admittance: Reflection
measurement)
Yt
Conversion: ON
(Admittance:
Transmission
measurement)
Ytsh
Conversion: ON
(Admittance:
Transmission-Shunt
measurement)
1/S
Conversion: ON (Inverse
S-parameter)
Conj
Conversion: ON
(Conjugation)
Power correction
PC
Error correction: ON
(Power calibration)
Receiver correction
RC
Error correction: ON
