Agilent Technologies E5071C - Page 695

E5071C
922
Device Test 8753ES E5071C
Limit
test
Limit test
table
• One per channel
• Number of segments:
Up to 18 per table
• One per trace
• Number of
segments: Up to
100 per table
Offset Definable Definable
Creating a
table by
using the
GPIB
command
Create a table by using two
or more commands
Create a table by
using one command
Reading the
results
• Per channel, Per
segment
• Pass/fail at each point,
• Number of points per
segment that failed
the
maximum/minimum,
• Stimulus value at a
failed point
• Pass/Fail of the
active trace on
each channel
•
Number of failed
points
• Stimulus value
at a failed point
Ripple test Available Available
Bandwidth test Available Available
