Agilent Technologies E5071C User Manual

Product Information
923
Display 8753ES E5071C
Memory
trace
Number • One per channel • One per trace
Data
math
• Data / Memory
• Data - Memory
• Data / Memory
• Data * Memory
• Data - Memory
• Data + Memory
Display • Data trace only.
• Memory trace only.
• Simultaneous
display of memory
traces and data
traces.
• Data math only.
• Data trace only.
• Memory trace only.
• Simultaneous
display of memory
traces and data
traces.
• Data math only.
• Simultaneous
display of data
math and memory
traces.
Frequency display
On/Off setting is
definable for all channels.
On/off setting is definable
channel by channel.
Graph layout
• Up to four graphs
can be displayed.
• Windows are
assigned to each
channel; up to 36
windows can be
displayed.
• Up to 16 graphs
can be displayed in
each window.
Math between data
traces
The results for channel
1/channel 2 can be
displayed on the trace for
channel 2.
Not available
Scale
Auto
Available Available
