Agilent Technologies E5071C User Manual

E5071C
926
Marker 8753ES E5071C
Number of markers
Up to five markers per
channel
Nine markers per trace
(exclude reference
marker)
Active marker One marker per channel One marker per trace
Delta marker
(Reference marker)
Designates the marker
displayed as the
reference marker.
You can designate the
reference marker
independently from the
markers displayed.
Marker coupling
Setting of
Couple/Uncouple
definable
Setting of
Couple/Uncouple
definable
(coupling available only
between markers on the
same channel)
Marker move mode
Continuous/discrete
(definable channel by
channel)
Continuous/discrete
(definable trace by trace)
Fixed marker
One marker definable
per channel
Not available
Marker value display
On/Off setting for the
marker value display
definable per channel
All marker values for
active traces are
displayed on each
channel. Display/No
Display setting for the
marker table displaying all
marker values definable.
Marker
search
Search
function
• Maximum
• Minimum
• Target value
• Bandwidth
• Maximum
• Minimum
• Target value
• Peak
Object of
search
• Active marker
• Arbitrary marker
(during remote
