Product Information
927
control)
• Active marker
(when manipulating
the front panel).
Parameters
for
bandwidth
search
• Bandwidth
• Bandwidth center
frequency
• Q factor
• Loss
• Bandwidth
• Bandwidth center
frequency
• Upper and lower
frequency of the
bandwidth
• Q factor
• Loss
Target
value
Definable for an active
marker
Definable for each marker
Target
transition
type
Not definable
Setting of
Positive/Negative
transition definable (per
marker)
Search
tracking
On/Off setting definable
for the active marker
(Markers other than the
active marker are
always turned off.)
On/Off setting definable
for each marker
Marker reading set
at a parameter
Values of the start,
stop, center, span, CW
frequency, and
reference line in the
sweep range
Values of the start, stop,
center, span, and
reference line in the
sweep range
Reading the marker
value (for remote
control)
Possible for the active
marker
Possible for any marker
