E5071C
1008
Calibration
• Overview
• Performing Calibration
• Defining Calibration Kits
• Standard Definitions
• Reading/Writing Calibration Coefficient Alone
• Clearing Calibration Data and Calibration Coefficients
Other topics about Performing Calibration
Overview
You need to execute calibration to eliminate error elements related to
measurement, thus allowing you to perform accurate measurement.
Performing Calibration (Obtaining calibration coefficients)
Selecting a Calibration Kit
To select a calibration kit, use the following command:
:SENS{1-160}:CORR:COLL:CKIT
Selecting a Calibration Type
The calibration coefficients are calculated based on the selected calibration
type. Therefore, before you can calculate the calibration coefficients, you
must select the appropriate calibration type by using one of the following
commands.
Calibration type Command
Response OPEN
:SENS{1-160}:CORR:COLL:METH:OPEN
SHORT
:SENS{1-160}:CORR:COLL:METH:SHOR
THRU
:SENS{1-160}:CORR:COLL:METH:THRU
Enhanced Response
:SENS{1-160}:CORR:COLL:METH:ERES
1-Port
:SENS{1-160}:CORR:COLL:METH:SOLT1
Full 2-Port
:SENS{1-160}:CORR:COLL:METH:SOLT2
Full 3-Port
:SENS{1-160}:CORR:COLL:METH:SOLT3
Full 4-Port
:SENS{1-160}:CORR:COLL:METH:SOLT4
