Agilent Technologies E5071C User Manual

Programming
1097
to the High level when the
trigger signal for the first
point is received. When
measurement of all
measurement points is
completed and the
instrument is ready to
receive the trigger signal
for the first point of the
next sweep, this signal
goes to the Low level
again.
22 /PORT C0 Input/Output
Bit 0 of port C (4 bit
parallel I/O port)
23 /PORT C1 Input/Output Bit 1 of port C.
24 /PORT C2 Input/Output Bit 2 of port C.
25 /PORT C3 Input/Output Bit 3 of port C.
26 /PORT D0 Input/Output
Bit 0 of port D (4 bit
parallel I/O port)
27 /PORT D1 Input/Output Bit 1 of port D.
28 /PORT D2 Input/Output Bit 2 of port D.
29 /PORT D3 Input/Output Bit 3 of port D.
30
PORT C
STATUS
Output
Port C status signal.This
signal is changed to the
High level when the port C
is configured to output
port. It is changed to the
Low level when the port is
configured to input port.
31
PORT D
STATUS
Output
Port D status signal. This
signal is changed to the
High level when the port D
is configured to output
port. It is changed to the
Low level when the port is
