Agilent Technologies E5071C User Manual

E5071C
1098
configured to input port.
32
/WRITE
STROBE
Output
A output port write strobe
signal. When data is
present (that is, output
level changes) on any of
the output ports, this
signal provides a negative
pulse.
33 /PASS FAIL Output
Each limit test's results
signal. This signal changes
to the High level when limit
test, bandwidth test, or
ripple test results return
FAIL. It changes to the Low
level when all limit test
results return PASS.
34
/SWEEP
END
Output
A sweep completion signal.
When measurement (all
sweeps of all channels) and
data calculation are
completed, this signal
provides a negative pulse.
35 +5V Output
Provides +5V DC power
supply for external
instruments.
36
/PASS FAIL
STROBE
Output
Each limit test's results
write a strobe signal. When
limit test result is present
on /PASS FAIL, this signal
provides a negative pulse.
