Agilent Technologies E5071C User Manual

E5071C
1130
measurement cycle finishes
and returns "fail" as the limit
test result for trace 12.
13 Trace 13 Limit Test Fail
Set to "0" when a
measurement cycle begins;
set to "1" when the
measurement cycle finishes
and returns "fail" as the limit
test result for trace 13.
14 Trace 14 Limit Test Fail
Set to "0" when a
measurement cycle begins;
set to "1" when the
measurement cycle finishes
and returns "fail" as the limit
test result for trace 14.
15 Not used Always 0
Issuing the *CLS command will clear all the bits in the questionable limit
channel {1-16} status event register.
Status Bit Definitions of the Questionable Limit Channel {1-16}
Extra Status Condition Register
Bit
Position
Name Description
0 Not used Always 0
1
Trace 15
Limit Test
Fail
Set to "0" when a measurement cycle
begins;
set to "1" when the measurement cycle
finishes and returns "fail" as the limit test
result for trace 15.
2
Trace 16
Limit Test
Fail
Set to "0" when a measurement cycle
begins;
set to "1" when the measurement cycle
finishes and returns "fail" as the limit test
result for trace 16.
