Agilent Technologies E5071C User Manual

Programming
1137
measurement cycle finishes
and returns "fail" as the
bandwidth test result for
trace 12.
13
Trace 13 Bandwidth Test
Fail
Set to "0" when a
measurement cycle begins;
set to "1" when the
measurement cycle finishes
and returns "fail" as the
bandwidth test result for
trace 13.
14
Trace 14 Bandwidth Test
Fail
Set to "0" when a
measurement cycle begins;
set to "1" when the
measurement cycle finishes
and returns "fail" as the
bandwidth test result for
trace 14.
15 Not used Always 0
Issuing the *CLS command will clear all the bits in the questionable
bandwidth limit channel {1-16} status event register.
Status Bit Definitions of the Questionable Bandwidth Limit Channel
{1-16} Extra Status Condition Register
Bit
Position
Name Description
0 Not used Always 0
1
Trace 15
Bandwidth Test
Fail
Set to "0" when a measurement cycle
begins;
set to "1" when the measurement cycle
finishes and returns "fail" as the
bandwidth test result for trace 15.
2
Trace 16
Bandwidth Test
Fail
Set to "0" when a measurement cycle
begins;
set to "1" when the measurement cycle
finishes and returns "fail" as the
bandwidth test result for trace 16.
