Agilent Technologies E5071C User Manual

Programming
1163
Trace 4
Measurement
parameter
S22
Data format Smith chart (Lin)
Full-scale value 2
Channel
2
Sweep type Linear
Sweep
range
Center value 1.9 GHz
Span value 500 MHz
Number of measurement
points
101
IF bandwidth 70 kHz
Power 0 dBm
Number of traces 4
Graph Layout Two graphs at left and right
Trace 1
Measurement
parameter
S21
Data format Log magnitude
Reference
division line
number
9
Reference
division line
value
2
Scale per
division
10 dBm
Trace 2
Measurement
parameter
S22
Data format Smith chart (Lin)
Full-scale value 2
