Segment table for channel 1
Segmen
t
Number
Start
valu
e
Stop
valu
e
Number of
measuremen
t points
IF
bandwidt
h
Powe
r
1
1.7
GHz
1.9
GHz
21 50 kHz 0 dBm
2
1.9
GHz
2
GHz
101 10 kHz
-10
dBm
3
2
GHz
2.2
GHz
21 50 kHz 0 dBm
Sample Program in Excel VBA
Sub Setup()
'
Dim defrm As Long
Dim vi As Long
Const TimeOutTime = 20000
Dim Allocate1 As String, Allocate2 As String, File As String
Dim Para1(4) As String, Para2(2) As String
Dim Fmt1(4) As String, Fmt2(2) As String
Dim Star1(3) As String, Stop1(3) As String
Dim IfBw1(3) As Double, IfBw2 As Double
Dim Power1(3) As Double, Power2 As Double
Dim Cent2 As Double, Span2 As Double
Dim RefLev1(4) As Double, RefLev2(2) As Double, Scale1(4) As Double, Scale2(2) As Double
Dim Segm As Integer, Nop1(3) As Integer, Nop2 As Integer
Dim NumOfTr1 As Integer, NumOfTr2 As Integer
Dim RefPos1(4) As Integer, RefPos2(2) As Integer
Dim SendData As String
'
Segm = 3 ' Number of Segment Ch.1 : 3
Star1(1) = "1.7E9" ' Start Frequency Ch.1 Segm.1: 1.7 GHz
Star1(2) = "1.9E9" ' Segm.2: 1.9 GHz
Star1(3) = "2E9" ' Segm.3: 2 GHz
Stop1(1) = "1.9E9" ' Stop Frequency Ch.1 Segm.1: 1.9 GHz
