Cisco Catalyst 4500 Series Command Reference Guide

2-623
Catalyst 4500 Series Switch Cisco IOS Command Reference—Release IOS XE 3.4.0SG and IOS 15.1(2)SG)
OL-27596 -01
Chapter 2 Cisco IOS Commands for the Catalyst 4500 Series Switches
set cos
If you specify a “from-field” category but do not specify the table keyword and the applicable
table-map-name argument, the default action will be to copy the value associated with the “from-field”
category as the CoS value. For instance, if you configure the set cos precedence command, the
precedence value will be copied and used as the CoS value.
You can do the same for the DSCP marking category. That is, you can configure the set cos dscp
command, and the DSCP value will be copied and used as the CoS value.
Note If you configure the set cos dscp command, only the first three bits (the class selector bits) of the DSCP
field are used.
Note If you configure the set cos qos group command, only the three least significant bits of the qos group
field are used.
Examples This example shows how to configure a policy map called cos-set and assign different CoS values for
different types of traffic. This example assumes that the class maps called voice and video-data have
already been created.
Switch# configure terminal
Switch(config)# policy-map cos-set
Switch(config-pmap)# class voice
Switch(config-pmap-c)# set cos 1
Switch(config-pmap-c)# exit
Switch(config-pmap)# class video-data
Switch(config-pmap-c)# set cos 2
Switch(config-pmap-c)# end
Switch#
This example shows how to configure a policy map called policy-cos and to use the values defined in a
table map called table-map1. The table map called table-map1 was created earlier with the table-map
(value mapping) command. For more information about the table-map (value mapping) command, see
the table-map (value mapping) command page.
This example shows how the setting of the CoS value is based on the precedence value defined in
table-map1:
Switch# configure terminal
Switch(config)# policy-map policy-cos
Switch(config-pmap)# class class-default
Switch(config-pmap-c)# set cos precedence table table-map1
Switch(config-pmap-c)# end
Switch#
Related Commands Command Description
match (class-map
configuration)
Defines the match criteria for a class map.
policy-map Creates or modifies a policy map that can be attached to multiple
ports to specify a service policy and to enter policy-map
configuration mode.
service-policy (policy-map
class)
Creates a service policy that is a quality of service (QoS) policy
within a policy map.

Cisco Catalyst 4500 Series Specifications

General

Series	Catalyst 4500 Series
Category	Switch
Layer Support	Layer 2, Layer 3
Form Factor	Modular chassis
Stackable	No
Chassis Slots	3, 6, 7, 10
Power Supply Options	AC, DC
Redundancy	Power supply, Supervisor engine
Network Management	Cisco IOS Software CLI, SNMP, Cisco Prime Infrastructure
Features	Security, QoS
Port Density	Up to 384 ports per chassis
Security Features	802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard
Supervisor Engine	8-E
