show ip wccp
Router Identifier: 10.10.11.10
Protocol Version: 2.0
Service Identifier: web-cache
Number of Service Group Clients: 1
Number of Service Group Routers: 1
Total Packets Redirected: 0
Process: 0
CEF: 0
Platform: 0
Redirect access-list: no_linux
Total Packets Denied Redirect: 0
Total Packets Unassigned: 0
Group access-list: -none-
Total Messages Denied to Group: 0
Total Authentication failures: 0
Total Bypassed Packets Received: 0
Table 33 describes the significant fields shown in the display.
show ip wccp web-cache detail
The following example displays web cache engine information and WCCP router statistics for the
web cache service:
Switch# show ip wccp web-cache detail
WCCP Client information:
WCCP Client ID: 10.10.10.2
Protocol Version: 2.0
State: Usable
Redirection: L2
Packet Return: GRE
Table 33 show ip wccp web-cache Field Descriptions
Field Description
Protocol Version Indicates that WCCPv2 is enabled.
Service Identifier Indicates which service is detailed.
Number of Service Group Clients Number of clients using the router as their home router.
Number of Service Group Routers The number of routers in the service group.
Total Packets s/w Redirected Total number of packets s/w redirected by the router.
Redirect access-list The name or number of the access list that determines which
packets will be redirected.
Total Packets Denied Redirect Total number of packets that were not redirected because they did
not match the access list.
Total Packets Unassigned Number of packets that were not redirected because they were not
assigned to any cache engine. Packets may not be assigned during
initial discovery of cache engines or when a cache is dropped
from a cluster.
Group access-list Indicates which cache engine is allowed to connect to the router.
Total Messages Denied to Group Indicates the number of packets denied by the group-list access
list.
Total Authentication failures The number of instances where a password did not match.
