EZ-USB FX3 Technical Reference Manual, Document Number: 001-76074 Rev. *F 357
GPIF_RIGHT_WAVEFORM
0xE0016000
10.7.45 GPIF_LEFT_WAVEFORM (continued)
continued on next page
GPIF_RIGHT_WAVEFORM Right Edge Waveform Memory Register
b71 b70 b69 b68 b67 b66 b65 b64
Beta[17:10]
R/W R/W R/W R/W R/W R/W R/W R/W
RRRRRRRR
00000000
GPIF_RIGHT_WAVEFORM Right Edge Waveform Memory Register
b63 b62 b61 b60 b59 b58 b57 b56
Beta[9:2]
R/W R/W R/W R/W R/W R/W R/W R/W
RRRRRRRR
00000000
GPIF_RIGHT_WAVEFORM Right Edge Waveform Memory Register
b55 b54 b53 b52 b51 b50 b49 b48
Beta[1:0] Alpha_Right[7:2]
R/W R/W R/W R/W R/W R/W R/W R/W
RRRRRRRR
00000000
GPIF_RIGHT_WAVEFORM Right Edge Waveform Memory Register
b47 b46 b45 b44 b43 b42 b41 b40
Alpha_Right[1:0] Alpha_Left[7:2]
R/W R/W R/W R/W R/W R/W R/W R/W
RRRRRRRR
00000000
GPIF_RIGHT_WAVEFORM Right Edge Waveform Memory Register
b39 b38 b37 b36 b35 b34 b33 b32
Alpha_Left[1:0] f1[4:0] f0[4]
R/W R/W R/W R/W R/W R/W R/W R/W
RRRRRRRR
00000000
GPIF_RIGHT_WAVEFORM Right Edge Waveform Memory Register
b31 b30 b29 b28 b27 b26 b25 b24
f0[3:0] Fd[4:1]
R/W R/W R/W R/W R/W R/W R/W R/W
RRRRRRRR
00000000
GPIF_RIGHT_WAVEFORM Right Edge Waveform Memory Register
b23 b22 b21 b20 b19 b18 b17 b16
Fd[0] Fc[4:0] Fb[4:3]
R/W R/W R/W R/W R/W R/W R/W R/W
RRRRRRRR
00000000
