RX100 S7
Upgrade and Maintenance Manual 155
Hard disk drives / solid state drives
7.1.5 Replacing the 2.5-inch SAS/SATA backplane
V CAUTION!
Follow the safety instructions in chapter "Important information" on
page 43.
7.1.5.1 Required tools
●
Preliminary and concluding steps: tool-less
●
Main steps: tool-less
7.1.5.2 Preliminary steps
Ê Perform the following procedures:
1. "Opening the rack door" on page 59
2. "Locating the defective server" on page 55
3. "Shutting down the server" on page 59
4. "Extending/removing the server from the rack" on page 60
5. "Opening the server" on page 64
6. Release all HDD/SSD modules and pull them out a few centimeters, see
section "Removing the 2.5-inch HDD/SSD module" on page 151
I The HDD/SSD modules need not to be removed. But if you want
to remove them nevertheless, check if all HDD/SSD modules are
uniquely identified so that you can reinsert them into their original
bays.
Field Replaceable Units (FRU)
Average task duration: 10 minutes
